BEP DC Panel - 24-Way - No Meter
Available @
Toronto, ON
Vancouver, BC
NJ, Warehouse
FL, Warehouse
This product may be available for purchase online. For pricing and availability, click the
"Ask a Question about this Product" button below to speak with our team.
Let us know your shipping destination and required quantity, and we will have a personalized quote ready for you.
DC Panel - 24-Way - No Meter
BEP Marine uses the highest quality materials in its range of Control
Panels, from the marine grade aluminium base plates to the Airpax magnetic
hydraulic circuit breakers.
Features
Specifications
Total Positions: 24 Loads
Circuit Breakers: 5X 5A, 8X 10A, 8X 15A, 1X 20A, 1X 25A, 1X 30A
Nominal Voltage: 12V
Maximum Amperage: 160A per bus
Dimensions: 7.9" X 13.9" X 2.5"
Neg Bus: 12 Way
BEP Marine uses the highest quality materials in its range of Control
Panels, from the marine grade aluminium base plates to the Airpax magnetic
hydraulic circuit breakers.
Features
- Marine Grade powder coated aluminium
- Airpax circuit breaker
- Stylish Contour Design fascia
- Green LED backlit labels
- Red LED indicates systems on
- Panels meet ABYC standards
Specifications
Total Positions: 24 Loads
Circuit Breakers: 5X 5A, 8X 10A, 8X 15A, 1X 20A, 1X 25A, 1X 30A
Nominal Voltage: 12V
Maximum Amperage: 160A per bus
Dimensions: 7.9" X 13.9" X 2.5"
Neg Bus: 12 Way
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Product Specifications
| Dimensions | 16" L × 11" W × 5" H |
|---|---|
| Shipping Weight | 6.6 lb |
| Country of Origin | NZ |
| Harmonized Code | 8537109070 |
Documentation
| Owner's Manual | Download PDF |
|---|
