TACO Marine Universal Leaning Post Backrest

The TACO Marine Universal Leaning Post Backrest is designed to fit Neptune and most standard leaning posts, offering practical comfort on the water. This American-made backrest features adjustable folding arms that align with rod holders, maximizing deck space when needed. The cool white cushioned surface is easy to clean and resists wear over time. Measuring 34" wide, 7-3/8" high, and 3" deep, it provides solid support without taking up excessive room. Installation is straightforward using pre-drilled holes in the marine lumber backing and included hardware. The folding arms store conveniently when not in use, and the unit is backed by a three-year limited warranty for reliable performance.

Features and Benefits:

Made in the USA
Universal design to fit Neptune Leaning Posts and most standard leaning posts
Arms install at desired width to fit rod holders
Cool, white, easy-to-clean, cushioned backrest
Arms fold for easy storage when not in use
Hardware included
Three year limited warranty

Dimensions:

Height: 7-3/8"
Extended Arm Height: 7-1/2"
Width: 34"
Depth: 3"

TACO Marine Universal Backrest Assembly Instructions

The cloth on the backrest has no holes or marks. Underneath the cloth on the non-cushion side of the backrest is marine lumber. Underneath the cloth are 8 pre-drilled holes.
Found near the middle-left section of the lumber is a series of 4 pre-drilled holes. The other 4 pre-drilled holes are near the right middle section.
Search for these holes by moving your hand across the cloth that rests on the lumber. Feel for the holes and mark the cloth when a hole is discovered.
Align the holes on the round pads of the swivel arms with the marks made on the cloth.
Install the provided 8 machine screws. (4 screws for the left arm and 4 screws for the right arm).
Place a screw through the hole of the round pad located at the end of the swivel arms and fasten each screw onto the pre-drilled holes on the lumber.
Once the left and right swivel arms are installed onto the backrest, the swivel arms will align with the two outer most rod holders on Taco Marine Leaning Posts.

Click here for TACO Marine's Universal Backrest Assembly Instructions
